C600E EBike LCD Display 36V 48V E-Bike Accessories Electric Bike Scooter Speed Control Panel For 5S Motor Controller

C600E EBike LCD Display 36V 48V E-Bike Accessories Electric Bike Scooter Speed Control Panel For 5S Motor Controller

$93.05 USD
$0.00 USD $93.05 USD
Sale Sold out
Description:

C600E Default 5S Protocol
The C600 E gives you a variety of displays to suit your riding needs.
The displays of C600E are:
3.1 Riding mode selection:
Displays the current riding mode.
3.2 Current display:
Displays the current discharge current of the controller, each frame is 2A.
2A.
3.3 Speed display:
Displays the current riding speed per hour.
3.4 Backlight:
In the power-on state, tap ON/OFF key to
light up the instrument backlight and turn on the headlight at the same time, the headlight symbol is displayed here.
The headlight symbol is displayed here.
3.5 Metric Mile Display: Displays the unit of speed currently selected by the user in the setup interface.
The speed unit selected by the user in the setting interface is displayed.
3.6 Information Display:
 SET: Blinks when entering the setup screen.
 PAS: Power assist gear display, default range 0-5 gears, default 0 gears at power on.
The default range is 0-5 gears, and the default is 0 gears at power on.
 Error: display the current fault code.
3.7 Riding information display:
 ODO:Display the total mileage ridden by the current user.
 TIME:Display the time when the user's speed is more than 1KM/H.
TIME: display the time when the user's speed is more than 1KM/H.
 TRIP1:Display the mileage of user's single ride.  TRIP2:Display the mileage of user's single ride.
 TRIP2:Display the mileage of the last ride after turning on the device.
30 seconds, and then automatically cleared.
 TOGO: Range (this function needs to be customized).
3.8 6KM:
When user long press "-" button for 2 seconds to turn on 6KM
boost, the word 6KM will be displayed here, and the e-vehicle will move forward at 6KM.
The vehicle will move forward at a constant speed of 6KM.
3.9 Battery information display:
 Battery capacity percentage (this function needs to be customized).
 Voltage: Display the current battery voltage.
 Battery discharge times (this function needs to be customized).
 Battery Capacity Display: Display the current battery level, when the battery level is low, it will display with a 1HZ signal.
When the battery level is low, it will blink with 1HZ.
Packaging:
1*Display
