Product Purchase Notes:

Description: KD718 5Pin waterproof connector

    Function Overview

The KD718 model meter offers a variety of features to meet your riding needs, including:

● Intelligent power indication

Motor power indication

●Assisted gear adjustment and indication

●Speed display (including real-time speed, maximum speed, average speed)

●Mileage display (including single mileage and total mileage)

●Assisted push control and display

●Riding time display

●Backlight control and display

●Error code display

USB connection indication

●Multiple parameter settings (e.g. wheel diameter, speed limit, battery level setting, power assist parameter setting, etc.)

Specification

●24/36V/48V power supply

●Meter rated operating current: 50mA

●Maximum operating current: 200mA

●Shutdown leakage current: <1μA

●Operating temperature: -20～60°C

●Storage temperature: -30～70°C

Operation

◆ Power on/off

Press the power button briefly to switch on the e-bike system and supply power to the controller. Press and hold the

power button for 2 seconds, the e-bike system is switched off. The e-bike system no longer uses battery power.

The leakage current is less than 1 μA when the e-bike system is switched off.

■ If the e-bike is not used for more than 5 minutes, the meter will automatically switch off. ◆Display Interface

When the instrument is switched on, it displays the real-time speed and single mileage (km) by default. Press "i" button briefly.

Display information in single mileage (km), total mileage (km), maximum speed (km/h), average speed (km/h).

The display switches between single mileage (km), total mileage (km), maximum speed (km/h), average speed (km/h), and riding time.

Cautions

Pay attention to the safety during use, and do not plug or unplug the meter while it is energised.

◆ Avoid bumping the instrument as much as possible.

◆ Please do not change the background parameter settings of the instrument, otherwise normal riding cannot be guaranteed.

◆ When the instrument can not be used normally, it should be sent for repair as soon as possible.

Packaging:



   1*LCD Display
